2026 Kioti CK3520 HST

Engine

• Model 3H-TM4B
• Engine Manufacturer KIOTI
• Power 34.90 hp (26 kW)
• Displacement 111.40 cu. in. (1,826 cc)
• RPM 2,600 rpm
• Fuel Type Diesel
• Fuel Capacity 9 gal (34 L)

Transmission

• Transmission Hydrostatic
• Shuttle Hydrostatic
• Travel Speeds Forward 3 Ranges, w/ infinite speeds
• Travel Speeds Reverse 3 Ranges, w/ infinite speeds
• Travel Speeds Minimum Speed 0 mph (0 km/h)
• Travel Speeds Maximum Speed 14.88 mph (23.94 km/h)
• Travel Speeds Min Reverse Speed 0 mph (0 km/h)
• Travel Speeds Max Reverse Speed 10.41 mph (16.76 km/h)

PTO

• PTO Type Independent
• PTO Power 30.90 hp (23 kW)
• Rear Speed 540
• Mid Speed 2,000 (Optional)

Drive Train

• Brakes Wet Disc Type
• Clutch None
• Steering Hydrostatic Power Steering

Hydraulics

• Pump Gear
• Pump Capacity 11.30 gpm (42.90 lpm)
• Lift Capacity 1,631 lb (740 kg)

Hitch

• Type Three Point
• Category Category 1
• Control Type Position
• Lift Capacity 1,500 lb (680 kg)

Dimensions

• Width 54.50 in (1,385 mm)
• Height 92.90 in (2,360 mm)
• Wheelbase 65.70 in (1,670 mm)
• Ground Clearance 13.40 in (340 mm)
• Front Tread 48.20 in (1,225 mm)
• Rear Tread 47.60 in (1,210 mm)
• Turning Radius 8.96 ft (2.73 m)
• Weight 2,921 lb (1,325 kg)
• Length with Hitch 120.90 in (3,070 mm)
