2026 Kioti CS2530HC

Engine

• Model 3L123
• Engine Manufacturer KIOTI
• Power 24.50 hp (18.30 kW)
• Displacement 75.20 cu. in. (1,233 cc)
• Fuel Type Diesel
• Aspirated Intercooler
• Fuel Capacity 6.60 gal (25.50 L)

Transmission

• Transmission Hydrostatic
• Shuttle Hydrostatic
• Main Gear 2-Range
• Travel Speeds Forward Infinite
• Travel Speeds Reverse Infinite
• Travel Speeds Minimum Speed 0 mph (0 km/h)
• Travel Speeds Maximum Speed 8.99 mph (14.47 km/h)
• Travel Speeds Min Reverse Speed 0 mph (0 km/h)
• Travel Speeds Max Reverse Speed 6.15 mph (9.90 km/h)

PTO

• PTO Type Independent
• PTO Power 19.30 hp (14.40 kW)
• Rear Speed 540 rpm
• Mid Speed 2,200 rpm

Drive Train

• Brakes Wet Multi Disc
• Clutch None
• Steering Hydraulic Power Steering

Hydraulics

• Pump Open Center
• Pump Capacity 7 gpm (26.40 lpm)
• Lift Capacity 700 lb (317 kg)

Hitch

• Type Three Point
• Category Category 1
• Control Type Position
• Lift Capacity 700 lb (318 kg)

dimensions

• Length with Hitch 102.90 in (2,613.70 mm)
• Height 82.60 in (2,098.04 mm)
• Width 48.30 in (1,226.82 mm)
• Ground Clearance 6.40 in (162 mm)
• Front Tread 44.60 in (1,132.84 mm)
• Rear Tread 48.30 in (1,226.82 mm)
• Turning Radius 8.20 ft (2.54 m)
• Weight 2,233.30 lb (1,013.01 kg)
